Western Star X-Series
Western Star 47X
Maneuverability Meets Durability
The Perfect Combination of Toughness and Lightness
With a 111.6-inch bumper-to-back-of-cab dimension, the 47X is built for work that demands superior visibility, a tight turning radius and efficient equipment packaging. Its lighter chassis and durable X-Series cab help protect payload without giving up vocational strength.
Built for Productive Vocational Work
Payload and upfit
A heavy-duty 9.5 mm single-channel rail is available for vocational strength with lower chassis weight, while QuickFit electrical interfaces simplify body integration.
Powertrain range
Engine choices span Cummins L9 and X12 options plus the Detroit DD13, covering 260 to 525 horsepower and up to 1,850 lb-ft of torque.
Operator support
A large windshield, available external cameras, active safety systems and an operator-focused cab help improve awareness and comfort.
Level Up Cab Life
Designed Around the Driver
The steel-reinforced aluminum cab combines weight savings with durable doors and hinges. Inside, the wing-style dash, intuitive controls, available premium insulation and configurable trim create a practical workspace for long vocational days.
Built for the Way You Work
The 47X is a maneuverable vocational platform for applications where visibility, payload, body installation, and tight operating spaces matter.
Construction
Its vocational frame supports infrastructure and construction work, including crane-truck bodies.
Dump and Mixer
The short bumper-to-back-of-cab layout helps meet local length and bridge-law needs for dump trucks and concrete mixers.
Logging and Hauling
Western Star identifies log-truck and heavy-haul work among the demanding applications supported by the X-Series cab.
Municipal Fleets
Snowplow-ready PTO options and flexible body upfit make the 47X a practical vocational platform for municipal operations.
47X, 49X and 49X Power Hood
How the X-Series Models Compare
Choose the dimensions, visibility, cooling capacity and power range that best fit the work. Specifications shown are published by Western Star; available configurations vary.
47X
Rugged and highly maneuverable, with visibility, handling and weight savings for demanding vocational work.
- Engine displacement
- 9L to 13L
- Radiator size
- 1,400 sq. in.
- Horsepower / torque
- 260 HP / 860 lb-ft to 525 HP / 1,850 lb-ft
- Bumper to back of cab
- 111.6 in.
- Forward visibility
- Best
- Air filtration
- Excellent
- Maximum sleeper
- 48 in.
- Turning radius
- 34.0 ft. with 20-ft. body
49X
A heavy-duty platform with the components and power for the toughest jobs and most demanding conditions.
- Engine displacement
- 12L to 16L
- Radiator size
- 1,400 sq. in.
- Horsepower / torque
- 350 HP / 1,350 lb-ft to 605 HP / 2,050 lb-ft
- Bumper to back of cab
- 121.5 in.
- Forward visibility
- Very good
- Air filtration
- Best
- Maximum sleeper
- 72 in.
- Turning radius
- 35.4 ft. with 20-ft. body
49X Power Hood
A modern long-and-tall design pairing comfort and style with maximum horsepower, torque and cooling capacity.
- Engine displacement
- 15L or 16L
- Radiator size
- 1,600 sq. in.
- Horsepower / torque
- 425 HP / 1,750 lb-ft to 605 HP / 2,050 lb-ft
- Bumper to back of cab
- 121.5 in.
- Forward visibility
- Good
- Air filtration
- Very good
- Maximum sleeper
- 36, 48, 60 or 72 in.
- Turning radius
- 35.4 ft. with 20-ft. body
Review the complete X-Series comparison on Western Star’s website.
Talk With a 47X Specialist
Contact Boyd Truck Centers to discuss body upfit, powertrain choices and available 47X inventory.
